The SANY SY85C is an 8.5-ton class crawler excavator powered by a Kubota V3800DI-T engine with a rated power of 60.7 kW. Combining robust power, stable performance, and agile handling, it is suitable for a wide range of applications, including earthworks, municipal projects, road construction, landscaping, and agricultural operations.
Equipped with a 0.34 m³ bucket, the SY85C offers a maximum digging radius of 6,660 mm and a maximum digging depth of 4,330 mm, meeting the operational requirements of various small-to-medium-sized projects. Additionally, its compact dimensions and 450 mm track shoe design ensure excellent maneuverability and adaptability to different job sites.
+
-
1. Powerful, Stable, and Efficient
Equipped with a Kubota V3800DI-T engine delivering a rated power of 60.7 kW and a maximum torque of 305.4 N·m, it meets diverse construction requirements.
2. Agile Operation and High Adaptability
With an operating weight of 8,500 kg, a 0.34 m³ bucket, and a swing speed of 11.2 rpm, it is well-suited for confined and complex job sites.
3. Powerful Digging Capability
Features a maximum bucket digging force of 63.6 kN, an arm digging force of 46.8 kN, and a maximum digging depth of 4,330 mm, ensuring outstanding operational performance.
4. Compact Design for Easy Transport
Transport dimensions are just 6,560 × 2,260 × 2,650 mm; the 450 mm track shoe width balances stability with maneuverability.
5. Versatile Application Across Multiple Scenarios
Suitable for earthworks, road construction, municipal projects, landscaping, agricultural work, and infrastructure development, offering excellent versatility and cost-efficiency.
01
Powerful Performance Equipped with a Kubota V3800DI-T engine, delivering a rated power of 60.7 kW and a maximum torque of 305.4 N·m.
02
Powerful Digging Features a maximum bucket digging force of 63.6 kN and a maximum digging depth of 4,330 mm, meeting diverse construction requirements.
03
Agile and Efficient Bucket capacity of 0.34 m³, swing speed of 11.2 rpm, and maximum digging radius of 6,660 mm.
04
Stable and Easy to Transport Operating weight of 8,500 kg, ground pressure of only 36 kPa, and transport dimensions of 6,560 × 2,260 × 2,650 mm, making it suitable for various construction environments.
| Category | Item | Specification |
|---|---|---|
| General Parameters | Model | SY85C |
| Model Class | 85 | |
| Excavator Tonnage | 8.5 t | |
| Travel Type | Crawler | |
| Bucket Type | Backhoe | |
| Application | General Purpose | |
| Engine (Diesel) | Engine Brand | Kubota |
| Engine Model | V3800DI-T | |
| Engine Type | 4-Cylinder, 4-Stroke, Direct Injection, OHV, Inline, Water-Cooled | |
| Rated Power | 60.7 kW | |
| Rated Speed | 2200 rpm | |
| Maximum Torque | 305.4 N·m | |
| Displacement | 3.769 L | |
| Performance | Operating Weight | 8500 kg |
| Bucket Capacity | 0.34 m³ | |
| Travel Speed (High/Low) | 5.0 / 2.9 km/h | |
| Swing Speed | 11.2 rpm | |
| Ground Pressure | 36 kPa | |
| Gradeability | 70% | |
| Bucket Digging Force | 63.6 kN | |
| Arm Digging Force | 46.8 kN | |
| Overall Dimensions | Overall Dimensions (L × W × H, Transport) | 6560 × 2260 × 2650 mm |
| Track Ground Length | 2340 mm | |
| Track Length | 2980 mm | |
| Track Shoe Width | 450 mm | |
| Track Gauge | 1810 mm | |
| Minimum Ground Clearance | 360 mm | |
| Minimum Swing Radius (Front Attachment) | 1990 mm | |
| Rear Swing Radius | 1885 mm | |
| Working Range | Maximum Digging Reach | 6660 mm |
| Maximum Digging Depth | 4330 mm | |
| Maximum Digging Height | 7260 mm | |
| Maximum Dumping Height | 5210 mm | |
| Maximum Vertical Digging Depth | 3080 mm | |
| Fluid Capacities | Fuel Tank Capacity | 160 L |
| Hydraulic Oil Tank Capacity | 120 L | |
| Engine Oil Change Capacity | 12 L |
The SANY SY85C is a versatile, efficient, and reliable 8.5-ton class crawler excavator. Powered by a Kubota engine with a rated power of 60.7 kW and equipped with a 0.34 m³ bucket, it delivers powerful digging force and outstanding operational performance. Its compact design, excellent maneuverability, and agile handling make it suitable for a wide range of applications—including earthworks, road construction, municipal projects, landscaping, and agricultural work—offering a cost-effective solution for overseas customers undertaking small-to-medium-sized projects.
