High Load Capacity: Rated load of 10 tons, ideal for large-scale engineering projects, mining operations, and heavy-duty material handling.
Exceptional Terrain Adaptability: Features a crawler chassis design capable of navigating muddy ground, sandy terrain, slopes, and rugged landscapes, ensuring stable operation.
Efficient Hydraulic System: Delivers smooth and responsive fork arm lifting, significantly enhancing the efficiency of heavy-load handling.
Robust Durability: Key structural components feature a reinforced design, ensuring high reliability during prolonged, heavy-duty operations.
Comfortable Operation: The spacious cab offers an expansive field of view and an ergonomic control layout, minimizing operator fatigue.
Multifunctional Capability: Supports a wide range of attachments, expanding operational scenarios and enabling a single machine to perform multiple tasks.
01
Exceptional Load-Bearing Capacity With a rated load of 10 tons, it effortlessly handles large-scale engineering projects, mining operations, and heavy-duty material handling tasks.
02
Superior Mobility and Stability Featuring a crawler chassis design, it adapts to muddy, sandy, sloped, and rugged terrain, ensuring more stable and reliable operation.
03
High-Efficiency Hydraulics and Precision Operation The optimized hydraulic system ensures smooth and rapid fork arm movements, significantly boosting operational efficiency and precision.
04
Operator Comfort and Versatility The spacious cab offers an expansive field of view and convenient controls; furthermore, it supports a wide range of attachments, enabling a single machine to perform multiple functions.
| No. | Item | Units | Parameters (XCF1006K) |
|---|---|---|---|
| 1 | Rated lifting capacity | kg | 10000 |
| 2 | Overall length | mm | 5423 |
| 3 | Overall width (wheel) | mm | 2169 |
| 4 | Overall width (frame) | mm | 2169 |
| 5 | Min. mast height | mm | 2850 |
| 6 | Cab height | mm | 2650 |
| 7 | Max. mast height | mm | 4280 |
| 8 | Wheelbase | mm | 2800 |
| 9 | Front overhang | mm | 720 |
| 10 | Track (front) | mm | 1600 |
| 11 | Track (rear) | mm | 1700 |
| 12 | Under mast clearance (unloaded/rated load) | mm | 250 |
| 13 | Middle of truck clearance (unloaded/rated load) | mm | 300 |
| 14 | Max. lifting height | mm | 3000 |
| 15 | Mast tilting (forwards/backwards) | ° | 6 / 12 |
| 16 | Dead weight | kg | 12450 |
| 17 | Max. lifting speed (unloaded) | mm/s | 360 |
| 18 | Max. lifting speed (rated load) | mm/s | 330 |
| 19 | Max. lowering speed (unloaded) | mm/s | ≤600 / ≥300 |
| 20 | Max. lowering speed (rated load) | mm/s | 330 |
| 21 | Min. turning radius | mm | 4055 |
| 22 | Travelling speed (unloaded) | km/h | 32 |
| 23 | Travelling speed (rated load) | km/h | 29 |
| 24 | Max. gradeability | % | 20 |
| 25 | Max. drawbar pull (rated load) | kN | 62 |
With a core set of advantages—including a 10-ton heavy-duty load capacity, exceptional terrain adaptability, and highly efficient hydraulic operational performance—the XCF1006K is capable of stably and efficiently handling heavy materials in mines, construction sites, and complex terrain environments. The machine features a robust and durable overall structure with highly reliable key components; furthermore, its comfortable cab and convenient controls ensure an excellent operating experience for the user. Thanks to its multifunctional operational capabilities and high uptime, the XCF1006K stands as the ideal choice among 10-ton class fork loaders for applications involving complex working conditions.
